Material:
Red wood such as Dark Red Meranti or the like
alternatively every other wood. Resinous woods, oak
teak and wood
Fitting:
Covers lying German a hand mark fitting with basic security.
Seal:
Circulating lip seal outside of the weathering zone in the wing,
exchangeably (additional impact seal against
additional price).
Rain rail:
Thermally separatly, screwed in with PVC end caps,
amluminium nature, darkly anodized or white burn-paints
with stick cover.
Glazing:
ISO windowpanes 4-16-4 WG 1,1 Ug.
Alternatively against additional price of special glasses and
phon stop glass.
Surface:
Extremely smooth surface and dimensional
accuracy by hydraulic planes. 1 x
in the exchange procedure primed, 2 x with
airbrush paints. Against
surcharge special colors and/or 2-colored painting.
Execution:
According to DIN 68 121 in different
wood strengths. Edges rounded.
Resistance against driving rain:
According to DIN 18 055, stress group C
|
